Electric Heating

190100

|  Parameter  | Value  |
| -------- | ------- |
| Heating capacity¹ | 8 kW |
| Flow rate coolant | 5–30 l/min
| Voltage range | 400–850 Vdc |
| Secundairy voltage | 9–36 Vdc |
| Controlled | CAN 2.0B (500 kb/s)
| Rating | IP67 |
| Size unit | 311 x 153 x 106 mm (L x W X H) |
| Weight | 3,2 kg |
| Protection | Over temperature, over current and under-voltage protection |
| Operating temperature | -40 °C to 80 °C |

¹ 15 l/min.

This compact electric liquid heater is engineered for efficient thermal management in both vehicle and industrial systems. It is designed to integrate seamlessly with existing control systems via CAN 2.0B communication.
The unit features built-in protection against over-temperature, overcurrent, and under-voltage conditions, ensuring safe and reliable operation even in harsh or demanding environments. Its versatile design allows for flexible installation and operation, making it suitable for a wide range of applications where precise temperature control is essential.

190139

|  Parameter  | Value  |
| -------- | ------- |
| Heating capacity¹ | 5 kW |
| Flow rate coolant | 5–30 l/min
| Voltage range | 210–455 Vdc |
| Secundairy voltage | 9–36 Vdc |
| Controlled | CAN 2.0B (500 kb/s)
| Rating | IP67 |
| Size unit | 311 x 153 x 106 mm (L x W X H) |
| Weight | 3,2 kg |
| Protection | Over temperature, over current and under-voltage protection |
| Operating temperature | -40 °C to 80 °C |

¹ 15 l/min.

This compact 5 kW electric liquid heater is engineered for efficient thermal management in vehicle and industrial systems. It operates across 210–455 VDC high voltage and 9–36 VDC low voltage, with seamless integration via CAN 2.0B communication. With a 5–30 l/min flow range, IP67 protection, and built-in safeguards against over-temperature, overcurrent, and under-voltage, the unit ensures reliable performance in harsh environments.

190140

|  Parameter  | Value  |
| -------- | ------- |
| Heating capacity  | 1,5 kW  |
| Primary Voltage    | 230 Vac    |
| Controlled    | External relay    |
| Size unit | 541 x 112 x 307 mm (L x W X H) |
| Weight    | 6,5 kg    |
| Operating temperature    | -40 °C to 50 °C    |

This 1.5 kW electric convector provides reliable air heating for industrial and transport use. Powered by ~230 V AC, it features a compact AISI 304 stainless steel housing and axial fan for efficient airflow. With a safety thermostat, 2500 V dielectric strength, and EN 45545-2, Hazard Level 3 (HL3) compliance, it ensures dependable performance. Laser‑engraved markings, EPDM gaskets, and IP‑rated grounding enhance safety, while its modular design allows easy adaptation with removable air‑outlet plates.
